Home > Face Recognition > Face Temperature Measurement
  • F6 Facial Recognition Temperature Scanner with infrared thermal
  • F6 Facial Recognition Temperature Scanner with infrared thermal
  • F6 Facial Recognition Temperature Scanner with infrared thermal
  • F6 Facial Recognition Temperature Scanner with infrared thermal
  • F6 Facial Recognition Temperature Scanner with infrared thermal

F6 Facial Recognition Temperature Scanner with infrared thermal

Share :
  • Product Description
  • Product Parameters
  • Download

The product is based on 200W RGB, 200W IR binocular camera, supports WIFI + 10 / 100M network and rich peripheral security interface, to meet the needs of user access control, can realize personnel authentication, personnel entry and exit management and attendance management.


Facial Attendance Machine Features

* Temperature measurement distance: the recommended use distance is 50cm

* IP grade 65, suitable for indoor and outdoor

* Support IC card, 4G, QR code module optional


F6 Facial Recognition Temperature Scanner with infrared thermalF6 Facial Recognition Temperature Scanner with infrared thermalF6 Facial Recognition Temperature Scanner with infrared thermalF6 Facial Recognition Temperature Scanner with infrared thermalF6 Facial Recognition Temperature Scanner with infrared thermalF6 Facial Recognition Temperature Scanner with infrared thermalF6 Facial Recognition Temperature Scanner with infrared thermal

Access control attendanceFace recognitionall-in-one machine terminal

Product module

F6

Productfeatures

major function

Access control, attendance, access gate

Usage environment

Indoor, outdoor

 4/16


resolution ratio

200 megapixels

200 megapixels

Vertical wide Angle

65°

65°

Horizontal wide Angle

40°

40°

White light supplement

support

Infrared light supplement

support

Coreparameters

system

android 11.0

CPU

RK3566 4x ARM CortexTM A55up to1.8GHz

SC

Memory 2G,storage 8G

human-computer interaction

display screen

8-inch, Full View,170°IPS LCD, resolution 800* 1280

touch screen

support

Human temperaturemeasurement module [Optional]

Test accuracy: 0.1

test error:<±0.5

Temperature measurement distance: the recommended use distanceis 50cm

Operating temperature: 15℃~40

communication mode

Ethernet

10/100Mbps Ethernet

WIFI

Compliance with the IEEE802.11b/g/n standard (2.4G)

4G[Optional]

CAT1, domestic full Netcom

RM

human face

support

IC card[optional]

support

certificate of identification

Network ID card [Optional]

Local ID card needs external connection [optional]

Interface

data interface

USB 2.0*2

electric relay

*1


gorge line

RS4851

Wigan

The 26bit/ 34bit protocol

Go out switch

*1 IExpandable]

Fire linkage

*1 [Expandable]

key

Upgrade key

Souce

adapter

DC12V/2A power supply

Environmental requifremenp

working temperature

-20℃~60

Operating humidity

20%90%(No condensation water drop state)

static electricity ESD

IEC61000-4-2,LEVEL3

levels of protection

IP65

Installation

two ways

Wall hanging version

Turnstile version
